EL Backlight is a next-generation planar light source which delivers lights evenly over entire panel. when it is powered. EL is used for LCD backlight and as a light source of various electronic appliances such as mobile phone, MP3 player, electronic diary, backlight watch, CD player, walkman, and PDA(Personal Digital Assistant). EL is thinner and more flexible than conventional backlight such as LED, and features luminescence of whole panel and low power consumption. Thin and light Uniform luminance Lower power consumption than conventional LED backlight Brightness adjustable   Widely used as LCD backlight   Applications: Mobile phone, MP3 player, electronic diary, electronic dictionary, backlight watch, voice pen, PDA(Personal Digital Assistant), pager and other industrial instruments. A Outer Size B Outer Size C Lighting Size D Lighting Size E 0.5 mm MIN F 0.5 mm MIN G G 5.08 mm PITCH T T 0.25 mm TYP. Thickness    General :                 Lamp type: Flexible Thick Film AC Others / Measuring Method Useful Life (half life) : >  3,000 hours 25°C, 65%RH,   110V, 400Hz  Electrical :               Nominal Lamp Operating Voltage: 110 Volts AC Nominal Lamp Operating Frequency: 400 Hz Max. Lamp Operating Voltage: 200 Volts AC Brightness  (Green) 55cd/m2 Max. Lamp Operating Frequency Option: 3 khz Current Consumption: <  0.2 mA/cm2 (@ 110 Volts, 400 Hz) DC Power Option: DC /AC Custom Inverter AC Power Option: AC/AC Custom Converter    Environmental :                        Operating temperature:.   -15°C  ~  + 75 °C Storage: -30°C ~  +85°C,  in a packaged state
